0 MGB & MGC 1968-74 Repair Manual

Models Covered:MGB & MGB/GT (1968-74)MGC & MGC/GT (1969)DESCRIPTIONRear axles are hypoid design with center line of pinion set below centerline of ring gear. The axle shafts can be serviced without removing axle from vehicle. All differential adjustments are performed using shims. No adjustments for axle shaft end play is necessary. A collapsible spacer is used on drive pinion shaft.AXLE RATIO AND IDENTIFICATIONOnly one basic axle design is used on these models. To determine axle ratio, divide number of ring gear teeth by number of pinion gear teeth.REMOVAL AND INSTALLATIONAXLE SHAFT AND BEARINGS1) With vehicle raised and supported, rear...

0 Toyota xB/BB Scion Repair Manual

Manufacturer: Toyota/ScionModel: Scion xB / BBYear: 2004Contains the following information and repairs for:IntroductionPreparationService SpecificationsDiagnosticsEngine Control SystemFuelEmission ControlEngine MechanicalExhaustCoolingLubricationIgnitionStarting and ChargingFront and Rear SuspensionTire and Wheel Drive ShaftBrake and Parking BrakeAutomatic and Manual TransmissionClutchSteering ColumnPower SteeringHeater and Air conditioningSupplemental Restraint SystemSeat BeltLightingWiper and WasherAudio and Visual SystemWiringCommunication SystemWindshieldInstrument PanelSeatTheft Deterrent and Door LockEngine Hood and DoorsExterior and...

0 Mercedes-Benz 1968-72 Split Housing

Models Covered:280 Models (1968-72)300 Models (1968-72)DESCRIPTIONAxle assembly is of split case design with hypoid type gears in which centerline of drive pinion is mounted below centerline of ring gears. Remove case half of permits inspection and service of differential. All adjustments, except pinion bearing preload, are performed using shims. Pinion bearing preload is set using a collapsible spacer. Some models use a limited slip differential, either as standard or optional equipment.AXLE RATIO AND IDENTIFICATIONAll models 1968-72 Mercedes Benz 280 and 300 models use the split case rear axle with single pivot type rear suspension. Some models...

0 Nissan Altima L32 U32 2008 Repair Manual

Manufacturer: NissanModel: Altima L32 U32Year: 2008Contains the following information and repairs for:Quick Reference IndexForewordGeneral InformationEngineHybridTransmission and DrivelineSuspensionBrakesSteeringRestraintsVentilation Heater and Air ConditionerBody InteriorBody Exterior, Doors, Roof and Vehicle SecurityDriver ControlsElectrical & Power ControlDriver Information and MultimediaCruise ControlMaintenancePower Supply Routing CircuitFuse Block Junction Box (J/B)Fuse, Fusible Link and Relay BoxIPDM E/R (Intelligent Power Distribution Module Engine)Comment SheetQuick Reference ChartDOWNLOADFile Size: 67 MBFile Type: PDF, ...

0 Drive Axles Gear Tooth Pattern Inspection

PRELIMINARY INSPECTIONWipe lubricant from internal parts, then rotate gears and inspect for wear or damage. Mount a dial indicator to housing and check backlash of several points around ring gear. Backlash must be within specifications at all points. If no defects are found, check gear tooth pattern.GEAR TOOTH CONTACT PATTERNNOTE - Drive pattern should be well centered on ring gear teeth. Coast pattern should be centered but may be slightly forward tow of ring gear teeth.Point ring gear teeth with suitable marking compound, then wrap a cloth or rope around drive pinion flange to act as a brake. Rotate ring gear until a clear tooth pattern is...

0 Mercedes-Benz 1975-77 Drive Axles Repair Guide

Models Covered:230240D280 Series300D450 Series6.9DESCRIPTIONAxle assembly is of integral carrier housing, hypoid gear type in which centerline of drive pinion is mounted below centerline of ring gear. Removable rear housing cover permits inspection and service of differential. Some models may also be equipped with limited slip differential. All adjustments, except pinion bearing preload, are performed using shims. Pinion bearing preload is set using a collapsible spacer.AXLE RATIO AND IDENTIFICATIONAll of the above mentioned Mercedes Benz models use the integral carrier rear axle with semi-floating arm rear suspension. Some models also have limited...

0 Mazda 1975-77 Drive Axles Repair Guide

Models Covered:GLCMizer808RE PickupRX-3SPRX-4CosmoDESCRIPTIONAxle housing is banjo type with removable differential carrier and semi-floating axle shafts. Ring and pinion are hypoid type, in which centerline of pinion is set below centerline of ring gear. Differential case may be either two pinion or four pinion design. The axle shafts are retained in housing by ball bearing and bearing retainers at axle housing outer ends.AXLE RATIO AND IDENTIFICATIONAll Mazda models use one basic type of rear axle assembly. Any differences in Removal and Installation or Overhaul procedures will be noted where they occur. To determine axle ratio, divide number...
